Davimac ED Series Seed Drills

Davimac ED Series Seed Drills


ED Seed Drill

Spacings:
Sowing Width:
Overall Width:
Overall Height:
Seed/Fert. Capacity:
Weight:
Disc Coulter Size:
Features:
16 Row / 20 Row

150mm / 150mm
2400mm / 3000mm
2780mm / 3380mm
1805mm (With tines on the ground)
Seed 375L, Fert 375L / Seed 425L, Fert 425L
1220kg / 1385kg
400mm
Quality 25mm coil tines, 3 Tool bars at 450mm spacings,
275mm from tip of tine to the ground when lifted.

Enquire Further
Davimac DF Series Seed Drills

Davimac DF Series Seed Drills


DF Seed Drill

Spacings:
Sowing Width:

Overall Width:

Overall Height:
Seed/Fert. Capacity:

Small Seed Capacity:
Weight:
Disc Coulter Size:
Features:
20 Row / 24 Row / 28 Row

125mm, 150mm
(125mm Spacings) N/A / 3000mm / 3500mm
(150mm Spacings) 3000mm / 3600mm / N/A
(125mm Spacings) N/A / 3050mm / 3550mm
(150mm Spacings) 3050mm / 3550mm / N/A
2070mm (With tines on the ground)
Seed 500L, Fert 500L / Seed 500L-615L, Fert 500L-615L /
Seed 615L, Fert 615L
90L / 90L-112L / 112L
1948kg / 2064-2325kg / 2457kg
400mm
Quality 25mm coil tines,
4 Tool bars at 475mm spacings,
275mm from tip of tine to the ground when lifted.

Enquire Further
Davimac SD Series Seed Drills

Davimac SD Series Seed Drills


SD Seed Drill

Spacings:
Sowing Width:

Overall Width:

Overall Height:

Seed/Fert. Capacity:
Small Seed Capacity:
Weight:
Disc Coulter Size:
Features:
16 Row / 20 Row / 22 Row

150mm, 175mm
(150mm Spacings) 2400mm / 3000mm / 3300mm
(175mm Spacings) 2800mm / 3500mm / 3850mm
(150mm Spacings) 3200mm / 3800mm / 4100mm
(175mm Spacings) 3550mm / 4250mm / 4600mm
2040mm(Coil Tines) , 2140mm(Spring Release Tines)
(With tines on the ground)
Seed 400L, Fert 400L / Seed 490L, Fert 490L / Seed 560L, Fert 560L
90L / 110L / 130L
1575kg / 1860kg / 2105kg
400mm
Quality 25mm coil tines (Optional 400 pound spring release tines),
3 Tool bars at 575mm spacings,
275mm from tip of tine to the ground when lifted.

Enquire Further
Davimac TD Series Seed Drills

Davimac TD Series Seed Drills


TD Seed Drill

Spacings:
Sowing Width:

Overall Width:

Overall Height:
Seed/Fert. Capacity:

Small Seed Capacity:
Weight:
Disc Coulter Size:
Features:
16 Row / 20 Row / 24 Row / 28 Row

150mm, 175mm
(175mm Spacings) N/A / N/A / 4200mm / 4900mm
(250mm Spacings) 4000mm / 5000mm / N/A / N/A
(175mm Spacings) N/A / N/A / 4950mm / 5600mm
(250mm Spacings) 4600mm / 5600mm / N/A / N/A
2450mm (With tines on the ground)
Seed 715L, Fert 715L / Seed 920L, Fert 920L / Seed 785L, Fert 785L / Seed 920L, Fert 920L
130L / 170L / 140L / 170L
2760kg / 3820kg / 3080kg / 4200kg
400mm
Quality Spring Release Tines (400 or 600 pound),
4 Tool bars at 550mm spacings,
325mm from tip of tine to the ground when lifted.
